Victron Energy SmartSolar MPPT 150 45 – SCC115045212 For Sale
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
MPPT: Ultra Fast Maximum Power Point Tracking
By constantly monitoring the voltage and current output of your solar (PV) panels, MPPT technology ensures that every drop of available power is rinsed out of your panels, and harvested for storage. The advantage of this is most noticeable when the sky is partially clouded, and light intensity is constantly changing.
Remote Monitoring and Control
Remotely control and monitor the extensive features of your SmartSolar MPPT charger with built-in bluetooth by pairing it with your smartphone or other device via VictronConnect. If your installation is connected to the internet Victron Remote Management Portal (VRM) provides access to the full power of your MPPT, anytime, anywhere; both services are free to use. For remote installations – even when there is no internet connection or phone signal nearby – you may be able to monitor your MPPT by bluetooth-pairing with a LoRaWAN (long-range wide area network) device, available optionally.
Bluetooth Smart built-in
The wireless solution to set-up, monitor, update and synchronise SmartSolar Charge Controllers.
VE.Direct
For a wired data connection to a Color Control GX, other GX products, PC or other devices
Advanced Maximum Power Point Detection in case of partial shading conditions
If partial shading occurs, two or more maximum power points may be present on the power-voltage curve. Conventional MPPTs tend to lock to a local MPP, which may not be the optimum MPP. The innovative BlueSolar algorithm will always maximize energy harvest by locking to the optimum MPP.
Outstanding conversion efficiency
No cooling fan. Maximum efficiency exceeds 98%. Full output current up to 40°C (104°F).
Flexible charge algorithm
Fully programmable charge algorithm (see the software page on our website), and eight preprogrammed algorithms, selectable with a rotary switch (see manual for details).
Extensive electronic protection
- Over-temperature protection and power derating when temperature is high.
-
- PV short circuit and PV reverse polarity protection.
-
- PV reverse current protection.
-
Internal temperature sensor
Compensates absorption and float charge voltage for temperature.
Optional external battery voltage and temperature sensing via Bluetooth
A Smart Battery Sense or a BMV-712 Smart Battery Monitor can be used to communicate battery voltage and temperature to one or more SmartSolar Charge Controllers.
Brand
Victron Energy
Manufacturer Part Number
SCC115045212
GTIN
8719076053026
Battery Voltage
12 24 48V Auto Select (software tool needed to select 36V)
Rated Charge Current
45A
Nominal PV power
12V: 650W 24V: 1300W 36V: 1950W 48V: 2600W
Max. PV short circuit current
50A
Maximum PV Open Circuit Voltage
150V absolute maximum coldest conditions 145V start-up and operating maximum
Maximum efficiency
98%
Charge Algorithm
multi-stage adaptive (eight pre-programmed algorithms)
Data Communication Port
VE.Direct
Protection Category
IP43 (electronic components), IP22 (connection area)
Dimensions
H130 x W186 x D70mm
Weight
1.25Kg
Warranty
5 Years
Title
Default Title
